| 規格 SIZE (Dash) | 規格 SIZE (in.) | 內徑I.D. (mm) | 外徑O.D. (mm) | 最大工作壓力Max.W.P. | 最小爆破壓力Min.B.P. | 試驗壓力P.P | 最小彎曲半徑Min.B.R.* | 參考重量W.T | ||
| Min | Max | Min | Max | (MPa) | (MPa) | (MPa) | (mm) | kg/m | ||
| -3 | 3/16 | 4.6 | 5.5 | 12.5 | 13.5 | 21 | 84 | 42 | 75 | 0.20 |
| -4 | 1/4 | 6.1 | 7.2 | 14.1 | 15.1 | 21 | 84 | 42 | 85 | 0.25 |
| -5 | 5/16 | 7.9 | 8.7 | 16.2 | 17.4 | 15.7 | 62.8 | 31.4 | 100 | 0.31 |
| -6 | 3/8 | 10.3 | 11.1 | 18.4 | 19.6 | 14 | 56 | 28 | 115 | 0.36 |
| -8 | 1/2 | 12.7 | 13.7 | 22.2 | 23.8 | 12.2 | 48.8 | 24.4 | 140 | 0.45 |
| -10 | 5/8 | 15.9 | 17.0 | 26.2 | 27.8 | 10.5 | 42 | 21 | 165 | 0.60 |
| -14 | 7/8 | 22.2 | 23.3 | 30.0 | 38.8 | 5.6 | 22.4 | 11.2 | 185 | 0.70 |
| -18 | 1 1/8 | 28.6 | 29.8 | 36.3 | 38.7 | 4.3 | 17.2 | 8.6 | 230 | 0.85 |
| -22 | 1 3/8 | 34.9 | 36.1 | 42.8 | 45.2 | 3.5 | 14.0 | 7 | 265 | 1.00 |
| -28 | 1 3/4 | 46.0 | 47.2 | 54.3 | 56.7 | 2.4 | 9.6 | 4.8 | 335 | 1.40 |
| -38 | 2 3/8 | 60.3 | 61.9 | 70.8 | 73.2 | 2.4 | 9.6 | 4.8 | 610 | 2.16 |
| -48 | 3 | 76.2 | 77.8 | 88.3 | 90.7 | 1.4 | 5.6 | 2.8 | 840 | 2.84 |
加*項僅供參考，具體以管體為準
